ST100 - Jeep JL-JT - FOX ATS Steering Stabilizer

apexchassis.com\/collections\/apex-chassis-parts\/products\/st100-jl-jt-fox-ats-steering-stabilizer

Be sure to check vehicle fitment below

With conventional steering stabilizers, turning in one direction creates an increase in pressure inside the stabilizer as the shaft occupies more volume in the body and displaces the oil. The repercussion is a push or pull steering force felt by the driver as the stabilizer attempts to return to its neutral state. To overcome this unidirectional force, dual opposing stabilizers are often used, but this requires additional mounting hardware and space.

The Factory Race Series 2.0 Stabilizer ATS utilizes an Adjustable Through Shaft (ATS) architecture that eliminates shaft fluid displacement throughout the stabilizer’s entire travel in both directions. The external piggyback reservoir provides additional fluid capacity and utilizes an Internal Floating Piston (IFP) to separate the fluid from the nitrogen gas charge to eliminate cavitation. For increased control that can be tailored to any driving style and setup, an external adjuster provides 24 clicks of adjustment to fine tune the feel. The result is highly customizable and consistent damping of unwanted steering feedback in a single, bolt-on stabilizer.

NOTE:
Will fit in OE position
May not fit if NON OE diff cover
Can be paired with:
Synergy Relocation Bolt: XP300
Apex Clamps: 2" Clamp Zinc DC104 or 2" Clamp Black DC150
Damper Bracket: TR186

Where it fits:
Vehicle Position: Front
Quantity per vehicle: 1

What it fits:
Jeep JL/JT 2018-2024
Jeep Gladiator 2019-2024

Warranty:
All warranties will be through FOX

The Special Sauce:

BUSHINGS
  • Quiet nitrile rubber allows for increased suspension articulation
SPECIAL FEATURES
  • Travel (IN): 8.10
  • Compressed (IN): 15.10
  • Extended (IN): 23.20
BODY
  • 2.0 inch impact extruded and CNC machined 6061-T6 clear anodized aluminum body resists rust over time
RESERVOIR
  • External reservoir design separates shock oil from the high-pressure nitrogen
COMPONENTS
  • Black-anodized, CNC-machined 6061-T6 billet aluminum
SHAFT
  • 5/8 inch hard chrome plated heat-treated alloy steel
PISTON
  • Race-developed high-flow piston design
SEALS
  • Redundant sealing pack system main seal, wiper seal, scraper seal
OIL
  • JM92 Advanced Suspension Fluid for improved performance at variable temperatures
ADJUSTMENTS
  • Adjuster - 24 clicks of adjustability

Installation Instructions
